Electric 24V (Li-Ion / Lead-Acid)
TCM SRS16-N3
TCM Stacker Trucks • Toyo Carriers Manufacturing Co., Ltd.
Kapasitas Utama
1.600 kg (1.6 Ton)
Titik Beban / Tinggi Angkat
600 mm / 3.300 – 5.400 mm
Tipe Daya / Penggerak
Electric 24V (Li-Ion / Lead-Acid)
Pabrikan Resmi
Toyo Carriers Mfg. (TCM)
Unit TCM SRS16-N3 Ride-On Pedestrian Stacker Truck (1.600 kg) merupakan model andalan pada kategori TCM Stacker Trucks dari TCM (Toyo Carriers Manufacturing Co., Ltd.) yang dirancang untuk memberikan performa angkat optimal (1.600 kg (1.6 Ton)), stabilitas kerja tinggi, serta efisiensi operasional terbaik. Didukung penuh oleh garansi resmi, ketersediaan suku cadang asli di Central Workshop Cakung, serta layanan teknisi mekanik keliling dari PT. Cemerlang Perkasa Teknologi di seluruh 38 provinsi Indonesia.
Unit Baru 100% Original TCM & Siap Operasional
Kualitas Global Toyo Carriers Manufacturing Co., Ltd.
10.000+ SKU Suku Cadang Asli Cakung & Teknisi 24/7
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM SRS16-N3
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM SRS16-N3
Karakteristik Rancang Bangun & Keunggulan Konstruksi TCM (TCM SRS16-N3):
stackers SRS Ride-On Stacker Li-ION 24v Voltage 1.6t Max Cap Versatile and compact . Stacker trucks are primarily used for stacking pallets at a range of heights, but they're very versatile machines, and perfect for moving pallets around a warehouse. Our pedestrian rider stackers have been designed with ergonomics and usability as the focus. The SRS offers a wide range of possible options and different capacities, making it suitable for a wide range of duties: from heavy industrial to light handling tasks, from intensive 24/7 shift work to intermittent usage. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM SRS16-N3 Ride-On Pedestrian Stacker Truck (1.600 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM Stacker Trucks, sistem penggerak 24V Heavy-Duty AC Electric Drive (Lithium-Ion / Lead-Acid) yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
stackers SRS Ride-On Stacker Li-ION 24v Voltage 1.6t Max Cap Versatile and compact . Stacker trucks are primarily used for stacking pallets at a range of heights, but they're very versatile machines, and perfect for moving pallets around a warehouse. Our pedestrian rider stackers have been designed with ergonomics and usability as the focus. The SRS offers a wide range of possible options and different capacities, making it suitable for a wide range of duties: from heavy industrial to light handling tasks, from intensive 24/7 shift work to intermittent usage. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM SRS16-N3 Ride-On Pedestrian Stacker Truck (1.600 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM Stacker Trucks, sistem penggerak 24V Heavy-Duty AC Electric Drive (Lithium-Ion / Lead-Acid) yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
Keunggulan Rancang Bangun & Performa
- Keunggulan TCM SRS16-N3 #1: The SRS offers a wide range of possible options and different capacities, making it suitable for a wide range of duties: from heavy industrial to light handling tasks, from intensive 24/7 shift work to intermittent usage.
- Keunggulan TCM SRS16-N3 #2: For multi-shift applications, the battery is placed on rollers, for quick and easy sideways changing. The narrow chassis allows the operator to pick up and position pallets in very confined spaces – especially important in production and other confined areas. The rounded edges also minimise the risk of damaged goods. There’s even a double pallet configuration for users wanting to maximise efficiency and productivity.
- Keunggulan TCM SRS16-N3 #3: Allowing for long travel distances and extended work cycles, the folding operator platform has excellent dampening, while the operator is protected by foldable protection bars (optional). A number of fixed platforms are available as options. The low chassis prevents foot injuries, and the compact design together with power steering (optional) facilitates manoeuvring in tight spaces.
- Keunggulan TCM SRS16-N3 #4: Truck Length 920mm-1,426mm Travel Speed with and without load 6-8.5km/h Turning Radius 1,743mm - 2,231mm Truck Width 748mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load SRS12-N3 1250 600 24 920 / 1280 748 1743 / 2080 6.0/6.0 SRS16-N3 1600 600 24 994 / 1355 748 1816 / 2155 6.0/6.0 SRS12I-N3 1250 600 24 993 / 1353 748 1815 / 2153 6.0/6.0 SRS16I-N3 1600 600 24 1023 / 1384 748 1845 / 2184 6.0/6.0 SRS12R-N3 1250 600 24 1312 748 2112 8.5 / 8.5 SRS16R-N3 1600 600 24 1386 748 2191 8.5 / 8.5 SRS12RI-N3 1250 600 24 1386 748 2190 8.5 / 8.5 SRS16RI-N3 1600 600 24 1415 748 2220 8.5 / 8.5 SRS12S-N3 1250 600 24 1312 748 2112 8.5 / 8.5 SRS16S-N3 1600 600 24 1386 748 2191 8.5 / 8.5 SRS12SI-N3 1250 600 24 1386 748 2190 8.5 / 8.5 SRS16SI-N3 1600 600 24 1415 748 2220 8.5 / 8.5 SRS16W-N3 1600 600 24 1034 / 1395 748 1856 / 2195 6.0 / 6.0 SRS16RW-N3 1600 600 24 1426 748 2231 8.5 / 8.5 SRS16SW-N3 1600 600 24 1426 748 2231 8.5 / 8.5 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
Aplikasi & Sektor Industri Ideal
Unit TCM SRS16-N3 Ride-On Pedestrian Stacker Truck (1.600 kg) pada kategori TCM Stacker Trucks sangat ideal untuk mendukung operasional Gudang Rak Bertingkat, Double-Deep Racking, Manufaktur, Farmasi, E-Commerce & Logistik Presisi di berbagai kawasan industri, pergudangan, dan pusat logistik di seluruh Indonesia.
Fitur & Keunggulan Utama (TCM SRS16-N3)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Fitur & Keunggulan Utama (TCM SRS16-N3)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Fitur Unggulan TCM SRS16-N3 #1: The SRS offers a wide range of possible options and different capacities, making it suitable for a wide range of duties: from heavy industrial to light handling tasks, from intensive 24/7 shift work to intermittent usage.
Fitur Unggulan TCM SRS16-N3 #2: For multi-shift applications, the battery is placed on rollers, for quick and easy sideways changing. The narrow chassis allows the operator to pick up and position pallets in very confined spaces – especially important in production and other confined areas. The rounded edges also minimise the risk of damaged goods. There’s even a double pallet configuration for users wanting to maximise efficiency and productivity.
Fitur Unggulan TCM SRS16-N3 #3: Allowing for long travel distances and extended work cycles, the folding operator platform has excellent dampening, while the operator is protected by foldable protection bars (optional). A number of fixed platforms are available as options. The low chassis prevents foot injuries, and the compact design together with power steering (optional) facilitates manoeuvring in tight spaces.
Fitur Unggulan TCM SRS16-N3 #4: Truck Length 920mm-1,426mm Travel Speed with and without load 6-8.5km/h Turning Radius 1,743mm - 2,231mm Truck Width 748mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load SRS12-N3 1250 600 24 920 / 1280 748 1743 / 2080 6.0/6.0 SRS16-N3 1600 600 24 994 / 1355 748 1816 / 2155 6.0/6.0 SRS12I-N3 1250 600 24 993 / 1353 748 1815 / 2153 6.0/6.0 SRS16I-N3 1600 600 24 1023 / 1384 748 1845 / 2184 6.0/6.0 SRS12R-N3 1250 600 24 1312 748 2112 8.5 / 8.5 SRS16R-N3 1600 600 24 1386 748 2191 8.5 / 8.5 SRS12RI-N3 1250 600 24 1386 748 2190 8.5 / 8.5 SRS16RI-N3 1600 600 24 1415 748 2220 8.5 / 8.5 SRS12S-N3 1250 600 24 1312 748 2112 8.5 / 8.5 SRS16S-N3 1600 600 24 1386 748 2191 8.5 / 8.5 SRS12SI-N3 1250 600 24 1386 748 2190 8.5 / 8.5 SRS16SI-N3 1600 600 24 1415 748 2220 8.5 / 8.5 SRS16W-N3 1600 600 24 1034 / 1395 748 1856 / 2195 6.0 / 6.0 SRS16RW-N3 1600 600 24 1426 748 2231 8.5 / 8.5 SRS16SW-N3 1600 600 24 1426 748 2231 8.5 / 8.5 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
Fitur Unggulan TCM SRS16-N3 #5: Struktur sasis baja berkekuatan tinggi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) untuk daya tahan operasional jangka panjang pada beban 1.600 kg (1.6 Ton).
Fitur Unggulan TCM SRS16-N3 #6: Sistem penggerak & hidrolik presisi (24V Heavy-Duty AC Electric Drive (Lithium-Ion / Lead-Acid)) yang memberikan respons halus, efisiensi energi optimal, dan Total Cost of Ownership (TCO) rendah.
Fitur Unggulan TCM SRS16-N3 #7: Desain ergonomis berorientasi operator dengan visibilitas luas dan radius putar kompak untuk manuver aman di lorong gudang maupun kawasan industri.
Fitur Unggulan TCM SRS16-N3 #8: Dukungan penuh garansi resmi, ketersediaan suku cadang asli di Central Workshop Cakung, serta layanan teknisi mekanik keliling di 38 provinsi Indonesia.
Parameter Teknis & Spesifikasi Lengkap (TCM SRS16-N3)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
Parameter Teknis & Spesifikasi Lengkap (TCM SRS16-N3)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
| Parameter Teknis | Nilai Spesifikasi |
|---|---|
| Merek / Brand | TCM |
| Pabrikan (Manufacturer) | Toyo Carriers Manufacturing Co., Ltd. |
| Designasi Kode Model | TCM SRS16-N3 |
| Tipe Unit | Ride-On Pedestrian Stacker Truck |
| Kategori Alat | TCM Stacker Trucks |
| Kapasitas Beban Utama (Load Capacity) | 1.600 kg (1.6 Ton) |
| Titik Beban (Load Centre) | 600 mm |
| Tinggi Angkat (Lift Height) | 3.300 – 5.400 mm |
| Sistem Penggerak / Power Source | 24V Heavy-Duty AC Electric Drive (Lithium-Ion / Lead-Acid) |
| Model Designation | SRS16-N3 |
| Load Capacity (Q) | 1600 kg |
| Load Centre (c) | 600 mm |
| Battery Voltage | 24 V (Lithium-Ion / Lead-Acid) |
| Length to Face of Forks (l2) | 994 / 1355 mm |
| Overall Chassis Width (b1) | 748 mm |
| Turning Radius (Wa) | 1816 / 2155 mm |
| Travel Speed (With / Without Load) | 6.0/6.0 km/h |
| Maximum Lift Height | Up to 5.400 mm |
| Sektor Operasional Ideal | Gudang Rak Bertingkat, Double-Deep Racking, Manufaktur, Farmasi, E-Commerce & Logistik Presisi |
| Kepatuhan K3 & Sertifikasi | Standar CE / EU Stage V / ISO9001 & Siap Riksa Uji SILO K3 Kemnaker RI |
| Cakupan Garansi Resmi | Garansi Resmi Unit & Komponen Utama Standar TCM |
| Dealer, PDI & Layanan Purna Jual | PT. Cemerlang Perkasa Teknologi (Central Workshop Cakung & Layanan Nasional 38 Provinsi) |
Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Garansi Resmi Standar Pabrikan
Perlindungan garansi resmi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) dan sertifikat Pre-Delivery Inspection (PDI) 48 titik untuk setiap pengadaan unit baru.
10.000+ SKU Suku Cadang Asli Cakung
Ketersediaan suku cadang orisinal (Genuine Parts) lengkap di gudang utama Central Cakung Jakarta Utara untuk menjamin minimum downtime operasional Anda.
Mobile Service Siaga 24/7
Tim teknisi mekanik bersertifikasi siap melakukan perawatan preventif berkala maupun perbaikan darurat langsung di lokasi gudang atau pabrik Anda.
Sertifikasi K3 & Uji SILO
Dukungan pengurusan sertifikasi kelayakan alat (SILO / K3 Kemnaker) resmi serta pelatihan pengoperasian dan perawatan harian bagi operator.
