TCM RTS 125
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM RTS 125
REACH RTS Man-Down VNA Li-ION 48v Voltage 1.5t Max Cap Ultimate Operator Comfort . To navigate the narrow aisles so typical of modern warehouse environments, this reach truck has been specially developed with a slender chassis and the smallest transfer aisle in the industry to suit sites with tight corridors or congested areas where size really does matter. Truck Length 3,010mm Travel Speed with and without load 12km/h Turning Radius 1,753mm Truck Width 1,450mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load RTS 125 1250 600 48 3010 1450 1753 12.0/12.0 RTS 150 1500 600 48 3010 1450 1753 12.0/12.0 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. RTS forklift trucks. The RTS truck is our solution to the problems created by narrow-aisle design in modern warehouses. Its slim profile and rotating forks allow operators to manoeuvre fully in very tight environments and it is the perfect truck when working alongside our High-Level Order Picker range. It enjoys the smallest transfer aisle in the industry - 3.7m - and is able to lift to a full 10.3m. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM RTS 125 Man-Down VNA Swivel-Fork Reach Truck (180° Turret Head) (1.250 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM VNA & Reach Trucks, sistem penggerak 48V VNA Guided-Aisle AC Electric Drive (Wire / Rail Guidance Option) yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
Keunggulan Rancang Bangun & Performa
- Keunggulan TCM RTS 125 #1: Truck Length 3,010mm Travel Speed with and without load 12km/h Turning Radius 1,753mm Truck Width 1,450mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load RTS 125 1250 600 48 3010 1450 1753 12.0/12.0 RTS 150 1500 600 48 3010 1450 1753 12.0/12.0 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. RTS forklift trucks. The RTS truck is our solution to the problems created by narrow-aisle design in modern warehouses. Its slim profile and rotating forks allow operators to manoeuvre fully in very tight environments and it is the perfect truck when working alongside our High-Level Order Picker range. It enjoys the smallest transfer aisle in the industry - 3.7m - and is able to lift to a full 10.3m.
- Keunggulan TCM RTS 125 #2: When used with guided aisle systems - either floor-mounted rails or under-floor wire - operators can concentrate entirely on stacking. Loads can be raised as soon as the truck is in the aisle, and performance gains from diagonal lift & travel are typically 15-20% faster than free-range trucks. Optional extras include a storage height pre-selector and a camera monitoring system that further enhance efficiency and visibility, as well as a unique cold-store option that provides the most robust cold-store cabin in the industry, offering complete driver protection insulation in temperatures down to minus 30C .
- Keunggulan TCM RTS 125 #3: Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
- Keunggulan TCM RTS 125 #4: That’s why we adopt a safety-first approach with our forklift design. Incorporating extensive safety features helps to reduce forklift truck accidents and ensure our trucks are reliable in real-world conditions and compliant with industry standards. This approach extends to our end-to-end support to ensure you have the tools you need to provide operators with the necessary safety training.
Aplikasi & Sektor Industri Ideal
Unit TCM RTS 125 Man-Down VNA Swivel-Fork Reach Truck (180° Turret Head) (1.250 kg) pada kategori TCM VNA & Reach Trucks sangat ideal untuk mendukung operasional Gudang Lorong Sempit (Narrow Aisle & Very Narrow Aisle / VNA), High-Bay Racking hingga 19 Meter & Cold Storage -30°C di berbagai kawasan industri, pergudangan, dan pusat logistik di seluruh Indonesia.
Fitur & Keunggulan Utama (TCM RTS 125)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Parameter Teknis & Spesifikasi Lengkap (TCM RTS 125)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
| Parameter Teknis | Nilai Spesifikasi |
|---|---|
| Merek / Brand | TCM |
| Pabrikan (Manufacturer) | Toyo Carriers Manufacturing Co., Ltd. |
| Designasi Kode Model | TCM RTS 125 |
| Tipe Unit | Man-Down VNA Swivel-Fork Reach Truck (180° Turret Head) |
| Kategori Alat | TCM VNA & Reach Trucks |
| Kapasitas Beban Utama (Load Capacity) | 1.250 kg (1.25 Ton) |
| Titik Beban (Load Centre) | 600 mm |
| Tinggi Angkat (Lift Height) | Up to 10.350 mm |
| Sistem Penggerak / Power Source | 48V VNA Guided-Aisle AC Electric Drive (Wire / Rail Guidance Option) |
| Model Designation | RTS 125 |
| VNA Configuration | Man-Down VNA Reach Truck with 180° Rotating Turret Forks (3.7m Min Transfer Aisle) |
| Load Capacity (Q) | 1250 kg |
| Load Centre (c) | 600 mm |
| Battery Voltage | 48 V (Lithium-Ion / Lead-Acid) |
| Overall Length (l1) | 3010 mm |
| Overall Chassis Width (b1) | 1450 mm |
| Turning Radius (Wa) | 1753 mm |
| Travel Speed (With / Without Load) | 12.0/12.0 km/h |
| Maximum Lift Height | Up to 10.350 mm (Optional -30°C Cold Store Cabin) |
| Sektor Operasional Ideal | Gudang Lorong Sempit (Narrow Aisle & Very Narrow Aisle / VNA), High-Bay Racking hingga 19 Meter & Cold Storage -30°C |
| Kepatuhan K3 & Sertifikasi | Standar CE / EU Stage V / ISO9001 & Siap Riksa Uji SILO K3 Kemnaker RI |
| Cakupan Garansi Resmi | Garansi Resmi Unit & Komponen Utama Standar TCM |
| Dealer, PDI & Layanan Purna Jual | PT. Cemerlang Perkasa Teknologi (Central Workshop Cakung & Layanan Nasional 38 Provinsi) |

Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Perlindungan garansi resmi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) dan sertifikat Pre-Delivery Inspection (PDI) 48 titik untuk setiap pengadaan unit baru.
Ketersediaan suku cadang orisinal (Genuine Parts) lengkap di gudang utama Central Cakung Jakarta Utara untuk menjamin minimum downtime operasional Anda.
Tim teknisi mekanik bersertifikasi siap melakukan perawatan preventif berkala maupun perbaikan darurat langsung di lokasi gudang atau pabrik Anda.
Dukungan pengurusan sertifikasi kelayakan alat (SILO / K3 Kemnaker) resmi serta pelatihan pengoperasian dan perawatan harian bagi operator.
