Lithium-Ion (24V)
TCM PSL12M-Q2
TCM Stacker Trucks • Toyo Carriers Manufacturing Co., Ltd.
Kapasitas Utama
1.200 kg (1.2 Ton)
Titik Beban / Tinggi Angkat
600 mm / Up to 2.000 mm
Tipe Daya / Penggerak
Lithium-Ion (24V)
Pabrikan Resmi
Toyo Carriers Mfg. (TCM)
Unit TCM PSL12M-Q2 LiTE Mono-Mast Pedestrian Lithium-Ion Stacker (1.200 kg) merupakan model andalan pada kategori TCM Stacker Trucks dari TCM (Toyo Carriers Manufacturing Co., Ltd.) yang dirancang untuk memberikan performa angkat optimal (1.200 kg (1.2 Ton)), stabilitas kerja tinggi, serta efisiensi operasional terbaik. Didukung penuh oleh garansi resmi, ketersediaan suku cadang asli di Central Workshop Cakung, serta layanan teknisi mekanik keliling dari PT. Cemerlang Perkasa Teknologi di seluruh 38 provinsi Indonesia.
Unit Baru 100% Original TCM & Siap Operasional
Kualitas Global Toyo Carriers Manufacturing Co., Ltd.
10.000+ SKU Suku Cadang Asli Cakung & Teknisi 24/7
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM PSL12M-Q2
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM PSL12M-Q2
Karakteristik Rancang Bangun & Keunggulan Konstruksi TCM (TCM PSL12M-Q2):
stackers PSL12M Pedestrian Stacker Li-ION 24v Voltage 1.2t Max Cap Compact and efficient . The PSL12M-Q2 is a compact, lightweight pedestrian stacker designed for light-duty operations where simplicity and reliability matter most. Perfect for narrow aisles and mezzanine applications, this mono-mast stacker delivers straightforward stacking performance. Ideal for small warehouses, retail stockrooms, and light manufacturing environments, the PSL12M-Q2 combines TCM's engineering excellence with streamlined specifications for everyday use. With a 1,200 KG load capacity and lift heights up to 2 meters, it's configured specifically for double pallet applications and limited lift height requirements. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM PSL12M-Q2 LiTE Mono-Mast Pedestrian Lithium-Ion Stacker (1.200 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM Stacker Trucks, sistem penggerak 24V Fast-Charging Integrated Lithium-Ion (Li-Ion) Battery yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
stackers PSL12M Pedestrian Stacker Li-ION 24v Voltage 1.2t Max Cap Compact and efficient . The PSL12M-Q2 is a compact, lightweight pedestrian stacker designed for light-duty operations where simplicity and reliability matter most. Perfect for narrow aisles and mezzanine applications, this mono-mast stacker delivers straightforward stacking performance. Ideal for small warehouses, retail stockrooms, and light manufacturing environments, the PSL12M-Q2 combines TCM's engineering excellence with streamlined specifications for everyday use. With a 1,200 KG load capacity and lift heights up to 2 meters, it's configured specifically for double pallet applications and limited lift height requirements. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM PSL12M-Q2 LiTE Mono-Mast Pedestrian Lithium-Ion Stacker (1.200 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM Stacker Trucks, sistem penggerak 24V Fast-Charging Integrated Lithium-Ion (Li-Ion) Battery yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
Keunggulan Rancang Bangun & Performa
- Keunggulan TCM PSL12M-Q2 #1: Ideal for small warehouses, retail stockrooms, and light manufacturing environments, the PSL12M-Q2 combines TCM's engineering excellence with streamlined specifications for everyday use. With a 1,200 KG load capacity and lift heights up to 2 meters, it's configured specifically for double pallet applications and limited lift height requirements.
- Keunggulan TCM PSL12M-Q2 #2: The steel chassis cover provides robust protection against the inevitable bumps and impacts of daily warehouse work, reducing maintenance costs and extending the truck's operational life. Fast-charging Li-Ion technology means you can charge anywhere, anytime, without the hassle of battery changes or maintenance schedules.
- Keunggulan TCM PSL12M-Q2 #3: Ergonomic design reduces operator fatigue during extended shifts, while automatic safety features like speed reduction in curves promote safer handling of loads. PIN code access ensures only authorised operators use the equipment, with optional RFID upgrade available for enhanced security and ease of use.
- Keunggulan TCM PSL12M-Q2 #4: Truck Length 800mm, 1,600mm, 2,000mm Travel Speed with and without load 4.2 / 4.5 km/h Turning Radius 1,350 mm Truck Width 800 mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load PSL12M-Q2 1200 600 24 1710 800 1350 4.2 / 4.5 PSL12E-Q2 1200 600 24 1710 800 1300 4.2 / 4.5 PSL12E(I)-Q2 1200 600 24 1752 800 1395 4.2 / 4.5 PSW13E(I)-Q2 (Two stage mast) 1300 600 24 1762 800 1400 4.2 / 4.5 PSW13E(I)-Q2 (Three stage mast) 1300 600 24 1776 806 1400 4.2 / 4.5 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
Aplikasi & Sektor Industri Ideal
Unit TCM PSL12M-Q2 LiTE Mono-Mast Pedestrian Lithium-Ion Stacker (1.200 kg) pada kategori TCM Stacker Trucks sangat ideal untuk mendukung operasional Gudang Rak Bertingkat, Double-Deep Racking, Manufaktur, Farmasi, E-Commerce & Logistik Presisi di berbagai kawasan industri, pergudangan, dan pusat logistik di seluruh Indonesia.
Fitur & Keunggulan Utama (TCM PSL12M-Q2)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Fitur & Keunggulan Utama (TCM PSL12M-Q2)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Fitur Unggulan TCM PSL12M-Q2 #1: Ideal for small warehouses, retail stockrooms, and light manufacturing environments, the PSL12M-Q2 combines TCM's engineering excellence with streamlined specifications for everyday use. With a 1,200 KG load capacity and lift heights up to 2 meters, it's configured specifically for double pallet applications and limited lift height requirements.
Fitur Unggulan TCM PSL12M-Q2 #2: The steel chassis cover provides robust protection against the inevitable bumps and impacts of daily warehouse work, reducing maintenance costs and extending the truck's operational life. Fast-charging Li-Ion technology means you can charge anywhere, anytime, without the hassle of battery changes or maintenance schedules.
Fitur Unggulan TCM PSL12M-Q2 #3: Ergonomic design reduces operator fatigue during extended shifts, while automatic safety features like speed reduction in curves promote safer handling of loads. PIN code access ensures only authorised operators use the equipment, with optional RFID upgrade available for enhanced security and ease of use.
Fitur Unggulan TCM PSL12M-Q2 #4: Truck Length 800mm, 1,600mm, 2,000mm Travel Speed with and without load 4.2 / 4.5 km/h Turning Radius 1,350 mm Truck Width 800 mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load PSL12M-Q2 1200 600 24 1710 800 1350 4.2 / 4.5 PSL12E-Q2 1200 600 24 1710 800 1300 4.2 / 4.5 PSL12E(I)-Q2 1200 600 24 1752 800 1395 4.2 / 4.5 PSW13E(I)-Q2 (Two stage mast) 1300 600 24 1762 800 1400 4.2 / 4.5 PSW13E(I)-Q2 (Three stage mast) 1300 600 24 1776 806 1400 4.2 / 4.5 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
Fitur Unggulan TCM PSL12M-Q2 #5: Struktur sasis baja berkekuatan tinggi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) untuk daya tahan operasional jangka panjang pada beban 1.200 kg (1.2 Ton).
Fitur Unggulan TCM PSL12M-Q2 #6: Sistem penggerak & hidrolik presisi (24V Fast-Charging Integrated Lithium-Ion (Li-Ion) Battery) yang memberikan respons halus, efisiensi energi optimal, dan Total Cost of Ownership (TCO) rendah.
Fitur Unggulan TCM PSL12M-Q2 #7: Desain ergonomis berorientasi operator dengan visibilitas luas dan radius putar kompak untuk manuver aman di lorong gudang maupun kawasan industri.
Fitur Unggulan TCM PSL12M-Q2 #8: Dukungan penuh garansi resmi, ketersediaan suku cadang asli di Central Workshop Cakung, serta layanan teknisi mekanik keliling di 38 provinsi Indonesia.
Parameter Teknis & Spesifikasi Lengkap (TCM PSL12M-Q2)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
Parameter Teknis & Spesifikasi Lengkap (TCM PSL12M-Q2)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
| Parameter Teknis | Nilai Spesifikasi |
|---|---|
| Merek / Brand | TCM |
| Pabrikan (Manufacturer) | Toyo Carriers Manufacturing Co., Ltd. |
| Designasi Kode Model | TCM PSL12M-Q2 |
| Tipe Unit | LiTE Mono-Mast Pedestrian Lithium-Ion Stacker |
| Kategori Alat | TCM Stacker Trucks |
| Kapasitas Beban Utama (Load Capacity) | 1.200 kg (1.2 Ton) |
| Titik Beban (Load Centre) | 600 mm |
| Tinggi Angkat (Lift Height) | Up to 2.000 mm |
| Sistem Penggerak / Power Source | 24V Fast-Charging Integrated Lithium-Ion (Li-Ion) Battery |
| Model Designation | PSL12M-Q2 |
| Product Series | TCM LiTE Range (Lithium-Ion) |
| Load Capacity (Q) | 1200 kg |
| Load Centre (c) | 600 mm |
| Battery Voltage | 24 V Lithium-Ion |
| Overall Truck Length (l1) | 1710 mm |
| Overall Chassis Width (b1) | 800 mm |
| Turning Radius (Wa) | 1350 mm |
| Travel Speed (With / Without Load) | 4.2 / 4.5 km/h |
| Maximum Lift Height | 2.000 mm |
| Security & Safety | PIN Code / Optional RFID Access & Automatic Speed Reduction in Curves |
| Sektor Operasional Ideal | Gudang Rak Bertingkat, Double-Deep Racking, Manufaktur, Farmasi, E-Commerce & Logistik Presisi |
| Kepatuhan K3 & Sertifikasi | Standar CE / EU Stage V / ISO9001 & Siap Riksa Uji SILO K3 Kemnaker RI |
| Cakupan Garansi Resmi | Garansi Resmi Unit & Komponen Utama Standar TCM |
| Dealer, PDI & Layanan Purna Jual | PT. Cemerlang Perkasa Teknologi (Central Workshop Cakung & Layanan Nasional 38 Provinsi) |
Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Garansi Resmi Standar Pabrikan
Perlindungan garansi resmi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) dan sertifikat Pre-Delivery Inspection (PDI) 48 titik untuk setiap pengadaan unit baru.
10.000+ SKU Suku Cadang Asli Cakung
Ketersediaan suku cadang orisinal (Genuine Parts) lengkap di gudang utama Central Cakung Jakarta Utara untuk menjamin minimum downtime operasional Anda.
Mobile Service Siaga 24/7
Tim teknisi mekanik bersertifikasi siap melakukan perawatan preventif berkala maupun perbaikan darurat langsung di lokasi gudang atau pabrik Anda.
Sertifikasi K3 & Uji SILO
Dukungan pengurusan sertifikasi kelayakan alat (SILO / K3 Kemnaker) resmi serta pelatihan pengoperasian dan perawatan harian bagi operator.
