Electric 96V Heavy-Duty
TCM FHB80H/9-E1
TCM Electric Counterbalance Forklifts • Toyo Carriers Manufacturing Co., Ltd.
Kapasitas Utama
8.000 kg (8.0 Ton)
Titik Beban / Tinggi Angkat
900 mm / 3.000 – 6.500 mm
Tipe Daya / Penggerak
Electric 96V Heavy-Duty
Pabrikan Resmi
Toyo Carriers Mfg. (TCM)
Unit TCM FHB80H/9-E1 96V Heavy-Duty Electric Counterbalance Forklift (8.000 kg) merupakan model andalan pada kategori TCM Electric Counterbalance Forklifts dari TCM (Toyo Carriers Manufacturing Co., Ltd.) yang dirancang untuk memberikan performa angkat optimal (8.000 kg (8.0 Ton)), stabilitas kerja tinggi, serta efisiensi operasional terbaik. Didukung penuh oleh garansi resmi, ketersediaan suku cadang asli di Central Workshop Cakung, serta layanan teknisi mekanik keliling dari PT. Cemerlang Perkasa Teknologi di seluruh 38 provinsi Indonesia.
Unit Baru 100% Original TCM & Siap Operasional
Kualitas Global Toyo Carriers Manufacturing Co., Ltd.
10.000+ SKU Suku Cadang Asli Cakung & Teknisi 24/7
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM FHB80H/9-E1
Deskripsi & Overview Produk
Ulasan lengkap rancang bangun, keunggulan teknis, dan sektor aplikasi operasional unit TCM FHB80H/9-E1
Karakteristik Rancang Bangun & Keunggulan Konstruksi TCM (TCM FHB80H/9-E1):
Electric Counterbalance FHB 4 Wheel Electric Counterbalance Forklift Li-ION 96v Voltage 12.0t Max Cap Class - leading energy efficiency . The ideal solution for the handling of heavy goods in all areas of application. The attention to every detail, creativity and technical expertise used in the design and development of the FHB60-120(H)(/9)-E1 are evident in features and design of the truck that combines the ability to lift heavy loads with a very compact and sturdy frame with the ease of driving, the extreme adaptability of performance and maximum operator comfort. The electronic control allows you to adjust the settings of the truck depending on the applications and wishes of the operators to increase the benefits in terms of high performances, comfort and long autonomies. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM FHB80H/9-E1 96V Heavy-Duty Electric Counterbalance Forklift (8.000 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM Electric Counterbalance Forklifts, sistem penggerak 96V High-Capacity AC Electric Drive (Lithium-Ion / Lead-Acid) yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
Electric Counterbalance FHB 4 Wheel Electric Counterbalance Forklift Li-ION 96v Voltage 12.0t Max Cap Class - leading energy efficiency . The ideal solution for the handling of heavy goods in all areas of application. The attention to every detail, creativity and technical expertise used in the design and development of the FHB60-120(H)(/9)-E1 are evident in features and design of the truck that combines the ability to lift heavy loads with a very compact and sturdy frame with the ease of driving, the extreme adaptability of performance and maximum operator comfort. The electronic control allows you to adjust the settings of the truck depending on the applications and wishes of the operators to increase the benefits in terms of high performances, comfort and long autonomies. Diproduksi sesuai standar global TCM (Toyo Carriers Manufacturing Co., Ltd.), unit TCM FHB80H/9-E1 96V Heavy-Duty Electric Counterbalance Forklift (8.000 kg) mengintegrasikan struktur sasis industri berkekuatan tinggi pada kategori TCM Electric Counterbalance Forklifts, sistem penggerak 96V High-Capacity AC Electric Drive (Lithium-Ion / Lead-Acid) yang handal dan hemat energi, serta kontrol presisi untuk keamanan dan produktivitas siklus kerja di Indonesia.
Keunggulan Rancang Bangun & Performa
- Keunggulan TCM FHB80H/9-E1 #1: The electronic control allows you to adjust the settings of the truck depending on the applications and wishes of the operators to increase the benefits in terms of high performances, comfort and long autonomies.
- Keunggulan TCM FHB80H/9-E1 #2: The ergonomic design of the drivers space, mounted on silent blocks and anti-vibration system allows to minimize vibration and to guarantee maximum comfort and ease of driving by reducing the fatigue of the operator during long shifts.
- Keunggulan TCM FHB80H/9-E1 #3: Truck Length 3,300mm-4,125mm Travel Speed with and without load 15-20km/h Turning Radius 2,605mm-3,705mm Truck Width 1,830mm-2,140mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load FHB60-E1 6000 600 96 3300 1830 2985 15 / 15 FHB60H-E1 6000 600 96 3300 1830 2650 20 / 20 FHB65-E1 6500 600 96 3300 1830 2985 15 / 15 FHB65H-E1 6500 600 96 3300 1830 2650 20 / 20 FHB70-E1 7000 600 96 3300 1830 2985 14.5 / 15 FHB70H-E1 7000 600 96 3300 1830 2650 20 / 20 FHB80-E1 8000 600 96 3640 1830 3300 14 / 15 FHB80H-E1 8000 600 96 3640 1830 2950 19 / 20 FHB80/9-E1 8000 900 96 3740 1900 3450 14 / 15 FHB80H/9-E1 8000 900 96 3740 1900 2950 17 / 18 FHB90-E1 9000 600 96 3680 1830 3300 15 / 18 FHB90H-E1 9000 600 96 3680 1830 2950 18 / 19 FHB100-E1 10000 600 96 3760 2000 3500 14 / 15 FHB100H-E1 10000 600 96 3760 2000 3500 16 / 18 FHB120H-E1 12000 600 96 4125 2140 3705 16 / 17 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
- Keunggulan TCM FHB80H/9-E1 #4: That’s why we adopt a safety-first approach with our forklift design. Incorporating extensive safety features helps to reduce forklift truck accidents and ensure our trucks are reliable in real-world conditions and compliant with industry standards. This approach extends to our end-to-end support to ensure you have the tools you need to provide operators with the necessary safety training.
Aplikasi & Sektor Industri Ideal
Unit TCM FHB80H/9-E1 96V Heavy-Duty Electric Counterbalance Forklift (8.000 kg) pada kategori TCM Electric Counterbalance Forklifts sangat ideal untuk mendukung operasional Pergudangan Indoor/Outdoor, Pusat Distribusi, Pabrik Manufaktur, Otomotif, Makanan & Minuman (FMCG) & Logistik 3PL di berbagai kawasan industri, pergudangan, dan pusat logistik di seluruh Indonesia.
Fitur & Keunggulan Utama (TCM FHB80H/9-E1)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Fitur & Keunggulan Utama (TCM FHB80H/9-E1)
Inovasi teknologi, ketangguhan sasis, dan ergonomi operator standar TCM
Fitur Unggulan TCM FHB80H/9-E1 #1: The electronic control allows you to adjust the settings of the truck depending on the applications and wishes of the operators to increase the benefits in terms of high performances, comfort and long autonomies.
Fitur Unggulan TCM FHB80H/9-E1 #2: The ergonomic design of the drivers space, mounted on silent blocks and anti-vibration system allows to minimize vibration and to guarantee maximum comfort and ease of driving by reducing the fatigue of the operator during long shifts.
Fitur Unggulan TCM FHB80H/9-E1 #3: Truck Length 3,300mm-4,125mm Travel Speed with and without load 15-20km/h Turning Radius 2,605mm-3,705mm Truck Width 1,830mm-2,140mm Specifications. Model Kg Capacity mm Load centre V Voltage mm Length mm Width mm Turning radius km/h Travel speed with / without load FHB60-E1 6000 600 96 3300 1830 2985 15 / 15 FHB60H-E1 6000 600 96 3300 1830 2650 20 / 20 FHB65-E1 6500 600 96 3300 1830 2985 15 / 15 FHB65H-E1 6500 600 96 3300 1830 2650 20 / 20 FHB70-E1 7000 600 96 3300 1830 2985 14.5 / 15 FHB70H-E1 7000 600 96 3300 1830 2650 20 / 20 FHB80-E1 8000 600 96 3640 1830 3300 14 / 15 FHB80H-E1 8000 600 96 3640 1830 2950 19 / 20 FHB80/9-E1 8000 900 96 3740 1900 3450 14 / 15 FHB80H/9-E1 8000 900 96 3740 1900 2950 17 / 18 FHB90-E1 9000 600 96 3680 1830 3300 15 / 18 FHB90H-E1 9000 600 96 3680 1830 2950 18 / 19 FHB100-E1 10000 600 96 3760 2000 3500 14 / 15 FHB100H-E1 10000 600 96 3760 2000 3500 16 / 18 FHB120H-E1 12000 600 96 4125 2140 3705 16 / 17 * Data provided is for guidance only. Actual data may vary depending on final truck configuration. Safety First. In a workplace where handling heavy machinery is at the core of operations, safety regulations and procedures must be top priority.
Fitur Unggulan TCM FHB80H/9-E1 #4: That’s why we adopt a safety-first approach with our forklift design. Incorporating extensive safety features helps to reduce forklift truck accidents and ensure our trucks are reliable in real-world conditions and compliant with industry standards. This approach extends to our end-to-end support to ensure you have the tools you need to provide operators with the necessary safety training.
Fitur Unggulan TCM FHB80H/9-E1 #5: Struktur sasis baja berkekuatan tinggi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) untuk daya tahan operasional jangka panjang pada beban 8.000 kg (8.0 Ton).
Fitur Unggulan TCM FHB80H/9-E1 #6: Sistem penggerak & hidrolik presisi (96V High-Capacity AC Electric Drive (Lithium-Ion / Lead-Acid)) yang memberikan respons halus, efisiensi energi optimal, dan Total Cost of Ownership (TCO) rendah.
Fitur Unggulan TCM FHB80H/9-E1 #7: Desain ergonomis berorientasi operator dengan visibilitas luas dan radius putar kompak untuk manuver aman di lorong gudang maupun kawasan industri.
Fitur Unggulan TCM FHB80H/9-E1 #8: Dukungan penuh garansi resmi, ketersediaan suku cadang asli di Central Workshop Cakung, serta layanan teknisi mekanik keliling di 38 provinsi Indonesia.
Parameter Teknis & Spesifikasi Lengkap (TCM FHB80H/9-E1)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
Parameter Teknis & Spesifikasi Lengkap (TCM FHB80H/9-E1)
Tabel parameter kapasitas beban, titik beban (load centre), dimensi teknis, dan sistem penggerak
| Parameter Teknis | Nilai Spesifikasi |
|---|---|
| Merek / Brand | TCM |
| Pabrikan (Manufacturer) | Toyo Carriers Manufacturing Co., Ltd. |
| Designasi Kode Model | TCM FHB80H/9-E1 |
| Tipe Unit | 96V Heavy-Duty Electric Counterbalance Forklift |
| Kategori Alat | TCM Electric Counterbalance Forklifts |
| Kapasitas Beban Utama (Load Capacity) | 8.000 kg (8.0 Ton) |
| Titik Beban (Load Centre) | 900 mm |
| Tinggi Angkat (Lift Height) | 3.000 – 6.500 mm |
| Sistem Penggerak / Power Source | 96V High-Capacity AC Electric Drive (Lithium-Ion / Lead-Acid) |
| Model Designation | FHB80H/9-E1 |
| Load Capacity (Q) | 8000 kg |
| Load Centre (c) | 900 mm |
| Battery Voltage | 96 V Heavy-Duty Electric |
| Truck Length to Face of Forks (l2) | 3740 mm |
| Overall Chassis Width (b1) | 1900 mm |
| Turning Radius (Wa) | 2950 mm |
| Travel Speed (With / Without Load) | 17 / 18 km/h |
| Operator Compartment | Silent-Block Anti-Vibration Isolated Cabin |
| Lift Height Range | 3.000 – 6.500 mm |
| Sektor Operasional Ideal | Pergudangan Indoor/Outdoor, Pusat Distribusi, Pabrik Manufaktur, Otomotif, Makanan & Minuman (FMCG) & Logistik 3PL |
| Kepatuhan K3 & Sertifikasi | Standar CE / EU Stage V / ISO9001 & Siap Riksa Uji SILO K3 Kemnaker RI |
| Cakupan Garansi Resmi | Garansi Resmi Unit & Komponen Utama Standar TCM |
| Dealer, PDI & Layanan Purna Jual | PT. Cemerlang Perkasa Teknologi (Central Workshop Cakung & Layanan Nasional 38 Provinsi) |
Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Garansi & Layanan Purna Jual Resmi TCM
Jaminan purna jual, ketersediaan suku cadang asli Cakung, dan teknisi siaga di seluruh Indonesia
Garansi Resmi Standar Pabrikan
Perlindungan garansi resmi standar TCM (Toyo Carriers Manufacturing Co., Ltd.) dan sertifikat Pre-Delivery Inspection (PDI) 48 titik untuk setiap pengadaan unit baru.
10.000+ SKU Suku Cadang Asli Cakung
Ketersediaan suku cadang orisinal (Genuine Parts) lengkap di gudang utama Central Cakung Jakarta Utara untuk menjamin minimum downtime operasional Anda.
Mobile Service Siaga 24/7
Tim teknisi mekanik bersertifikasi siap melakukan perawatan preventif berkala maupun perbaikan darurat langsung di lokasi gudang atau pabrik Anda.
Sertifikasi K3 & Uji SILO
Dukungan pengurusan sertifikasi kelayakan alat (SILO / K3 Kemnaker) resmi serta pelatihan pengoperasian dan perawatan harian bagi operator.
